Key Features
- Accommodates 1" of lateral drift in each direction, and 1" of upward and downward vertical deflection
- Unique design and placement of the anchorage slots allows for closer attachment of anchorage to the clip bend, providing increased load capacity
- The HWDC5.25 clip has three slots located at the anchorage leg allowing for attachment at the outer slots (anchorage pattern — centered) for maximum capacity or anchorage to the adjacent slots (anchorage pattern — off center) for walls that overhang the edge-angle or beam-edge
- Stiffening ribs are placed in between anchorage slots through the bend to provide additional strength and stiffness
- Simpson Strong-Tie® No-Equal® stamps mark the center of the slots to help ensure proper shouldered screw and anchor placement
Product Includes
- (55) XLSH78B1414 shoulder screws are provided with each order
Material
- 97 mil (12 ga.), 50 ksi
Finish
- Galvanized (G90)
