The ECCOQ is designed to provide strong column-beam connections in end-of-beam applications on top of steel members. The column cap features a design without legs, enabling a field-welded attachment to steel columns and beams. The seat of the column cap provides additional surface area for bearing that extends beyond the side of the column. This helps distribute the load from the beam and provide support for the connection. The ECCOQ uses Strong-Drive® SDS Heavy-Duty Connector screws for fast installation and to attach to a greater net section area of the column than a bolt attachment normally entails.
Key Features
- The SDS screws provide a lower profile than standard through bolts
- Diamond holes for temporary fastening
Material
- ECCOQ3, ECCOQ4, ECCOQ4.62, ECCOQ6 — 7 gauge; all others — 3 gauge
Finish
- No coating
Options
- For rough-cut lumber sizes, provide dimensions.
- Other custom column caps are available. Contact Simpson Strong-Tie.
